Slurry Collector Round Dust and Water Management Select Sizes
Request a Quote for Pricing
Prices vary based on market conditions. Fill out the "Request a Quote" form or contact us for the latest pricing.
Description
The round slurry collector captures wastewater and abrasive stone slurry at the borehole surface during handheld or rig-mounted wet diamond core drilling. Its flexible rubber double-seal matrix supports source capture, including inverted drilling, while the high-impact structural polymer body provides a durable containment interface. Connect it to a compatible industrial vacuum through the standard tapered extraction port to help control drilling water and reduce post-drilling cleanup on finished surfaces. Select the collector opening to match the core barrel, with sizes available from 65 mm to 430 mm.
Highlights
- Captures wastewater and abrasive stone slurry directly at the borehole surface
- Designed for handheld and rig-mounted wet diamond core drilling
- Flexible rubber double-seal matrix is optimised for inverted drilling
- High-impact, heavy-duty structural polymer body
- Standard industrial tapered port connects to vacuum extraction hoses
- Supports real-time wastewater suction and silica dust containment
- Compatible companion vacuum models include W 70 P, W 250 P, S 13 and DE 110i
- Compatible companion drill stand series include DS 150, DS 250 and DS 500
- Available with internal collector openings from 65 mm to 430 mm
- Maximum core bit capacity up to 420 mm
Specifications
| Brand | Husqvarna |
| Official Part Name | Slurry Collector (Round) |
| Max Core Bit Capacity | Up to 420 mm |
| Internal Collector Opening | 65 mm, 110 mm, 130 mm, 160 mm, 180 mm, 210 mm, 220 mm, 260 mm, 310 mm, 360 mm, 410 mm, 430 mm |
| Companion Slurry Vacuums | Husqvarna W 70 P, W 250 P, S 13, DE 110i |
| Companion Drill Stand Series | Husqvarna DS 150, DS 250, DS 500 |
| Tool Application Matching | Handheld and rig-mounted wet diamond core drilling |
| Primary Body Material | High-impact, heavy-duty structural polymers |
| Suction Seal System | Flexible rubber double-seal matrix |
| Hose Attachment Connection | Standard industrial tapered vacuum extraction port |
| Net Physical Weight | 1.1 kg |
| Core Function | Real-time wastewater suction, silica dust containment |
| Variant | Default Title |
Special Notes
- No warranty or accessory inclusions are specified
- verify the warranty and included items with Technomec
- Confirm motor power and spindle thread compatibility with your drill before use
